The Alnico material (composed predominantly of aluminum, nickel, and cobalt with minor amounts of other elements including titanium and copper) is manufactured through either a Casting or Sintering process. Compared to modern materials alnico has a low coercivity. The main advantage of alnico is the very low temperature coefficient and the wide temperature range from -273 Celsius to more than +400 Celsius for practical use.

•Product Name:

Isotropy AlNiCo Bonded Magnet

•Model Number:

TC-AlNiCo-Bonded

•Description:

Characteristics:

Good temp. Stability (temp. coefficient of Br is about ?C0.02%/K) bonded alnico magnet, bonded alnico magnets

Excellent magnetic evenness and stability

Strong anti-demagnetization

Application:

Due to the characteristics of above mentioned. It is widely used as magnetic driven bearing of power energy measuring instrument.

High stability magnetic sensor

Automatic control surveying instrument bonded alnico magnet, bonded alnico magnets

Magnetic properties and physical features of isotropic AlNiCo bonded magnets

CHARACTERS

1) Compact crystal, high intensity, good chemistry Stability, strong anti-corrosion.

2) Even elements, excellent and stable magnetic performance;

3) Excellent temperature stability (temp. coefficient of Br is the smallest among all of the other permanent magnets.)

4) Highest usage temperature reach 500 Celsius

5) Suitable for small volume and complex shape and magnet assemble for sintered Alnico.APPLICATION

1) Inner magnetic voltmeter/ammeter, electronic type power energy measuring instrument, avometer, flow meter;

2) Amide range of magnetic sensor, polarized relay, temperature and pressure controller;

3) Buzzer of Mobile phone, hearing aids, mini speaker;

4) Lighter of automobile, odometer of automobile and motorcycle, permanent motor, adsorptive appliance;

Widely applied in high stability fields as aviation, space flight, and military technology.



 Name: AlNiCo magnets

 Advantages:

AlNiCo magnets are very good in temperature properties , its temperature coefficient is very low, so the change of magnetic properties is low under high temperature. The maximum

 working temperature can be as high as 550 º C .

AlNiCo magnets have good corrosion resistance characteristic . No coating is needed for

surface protection.



disadvantages:

The coercive force of AlNiCo magnets is very low , so it can be easily effected by reverse

magnetic force, impact or touched by iron. This means that they can be easily demagnetized

 by external influences. thus  , AlNiCo magnets should not be stored and packed with the same

 poles opposing each other.  open circuit, the ration of length/diameter (L/D) should be at least

 4: 1. With shorter length, AlNiCo magnets are  unstable  in open circuit.



applications:

The Alnico (Aluminum, Nickel, Cobalt) family was introduced in the 1930"s. It"s characterized by

 excellent temperature stability, high residual induction, relatively high energies and resistant to

 corrosion. These were the first materials specifically designed for permanent magnets to be used

 in meters and inst
